AGM Deep Cycle Batteries
Photovoltaic Solar Panel 175W Polycrystalline System House Chalet Motorhome
VE175P
€100.17
VAT included
10 %
€91.06 Vat excl.
Photovoltaic Solar Panel 170W 12V Polycrystalline silicon, suitable for powering motor homes, boats, cottages, country houses, video surveillance systems, radio etc.
  |
Photovoltaic Solar Panel 175W 12V Polycrystalline |
Photovoltaic Solar Panel 175W Polycrystalline silicon, ideal for the realization of both grid-connected Photovoltaic (Photovoltaic ON-GRID) and both off-grid Photovoltaic (Photovoltaic OFF-GRID).
Main features
• Low voltage-temperature coefficient enhances high-temperature operation.
• Exceptional low-light performance and high sensitivity to light across the entire solar spectrum.
• Sealed, waterproof, multi-functional junction box gives high level of safety.
• High performance bypass diodes minimize the power drop caused by shade.
• Advanced EVA (Ethylene Vinyl Acetate) encapsulation system with triple-layer back sheet meets the most stringent safety requirements for high-voltage operation.
• A sturdy, anodized aluminium frame allows modules to be easily roof-mounted with a variety of standard mounting systems.
• Highest quality, high-transmission tempered glass provides enhanced stiffness and impact resistance.
• High power models with pre wired quick-connect system with (PV-ST01) connectors.
Warrenty
 |
5 years above the product |
 |
25 Linear years of warranty on production |
Certifications
Electrical features
Product Code: VE175P
Peak Power (pmax): 175W
Voltage at Pmax (Vmp): 19.28V
Power at Pmax (Imp): 9.08A
Maximum system voltage: 1000V
Dimensions: 148.5 x 66.8 x 3 cm
Power tolerance: 0/+3%
Open circuit voltage (Voc): 23.32V
Short circuit current (Isc): 9.80A
Number of cells 36
Weight: 11 kg
Downloads
 |
Datasheet EN [LINK] |
Customer Service
 |
0882 22 82 47 | |
 |
[email protected] | |
- Product Code
- VE175P
- Nominal Output (Pmax) W
- 175W
- Nominal Voltage V
- 12V
- Open Circuit Voltage (Voc) V
- 23.32
- Short Circuit Current (Isc) A
- 9.80
- Nominal Voltage at Pmax (Vmp) V
- 19.28
- Nominal current at Pmax (Imp) A
- 9.08
- Maximum System Voltage
- 1000V DC
- Connector Type
- MC4 o connettori compatibili
- Junction Box
- IP65 rated
- Type Panel
- framed
- Product Origin
- Asian
- Cell type
- Polycrystalline
- Number of cells
- 36
- Dimensions
- 148.5 x 66.8 x 3 cm
- Weight
- 11Kg
