SLS-1P5K-S6
€736.71
VAT included 10 %

€669.74 Vat excl.

Solis string inverter is designed for residential PV plants. The maximum input current per string is 14A, compact and lightweight design, bring easy installation. The protection level is increased to IP66. Integrated AFCI function can proactively reduce the risk of fire.



Single-phase string inverter 5kW Solis S6 double MPPT DC switch

Solis string inverter is designed for residential PV plants. The maximum input current per string is 14A, compact and lightweight design, bring easy installation. The protection level is increased to IP66. Integrated AFCI function can proactively reduce the risk of fire.

  • Max. efficiency 97.7%;
  • String current up to 14A;
  • Super high frequency switching technology;
  • Wide voltage range and low startup voltage;
  • 2 MPPT design with precise MPPT algorithm;
  • Intergrated Export Power Manager (EPM);
  • AFCI protection, proactively reduces fire risk;
  • Compact and lightweight;
  • Friendly and adaptable connection to the grid.

For more details, download the following documents:

Technical features:

Input DC
Recommended max. PV power 7.5kW
Max. input voltage 600V
Rated voltage 330V
Start-up voltage 120V
MPPT voltage range 90-520V
Max. input current 14A
Max. short circuit current 22A
MPPT number/Max. input strings number 2/2
Output AC
Rated output power 5kW
Max. apparent output power 5 kVA
Max. output power 5kW
General Data
Dimensions (WxHxD) 310 x 543 x 160mm
Weight 12 kg
Self consumption(night) <1W
Ingress protection IP66
Safty/EMC standard IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4
Grid connection standard G98 or G99, VDE-AR-N 4105 / VDE V 0124, EN 50549-1, VDE 0126 / UTE C 15 / VFR:2019, RD 1699 / RD 244 / UNE 206006 / UNE 206007-1, CEI 0-21, C10/11, NRS 097-2-1, EIFS 2018.2, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530, MEA, PEA
Features
DC connection MC4 connector
AC connection Quick connection plug
Display LCD
Communication RS485, Optional: Wi-Fi, GPRS


Customer Service

0882 22 82 47
[email protected]

MPPT number
2
Typology
Single-phase
Inverter power
5kW
8370000016601
