Inverter 430W 12V 500VA Victron Energy Multi 12/500/20-16

Inverter/chargers MultiPlus 1300W 24V 1600VA Victron Energy 24/1600/40-16

Name: Inverter/chargers MultiPlus 1300W 24V 1600VA Victron Energy 24/1600/40-16
Brand: Victron Energy
SKU: PMP242160000
Price: 832.76 EUR
Availability: InStock

Reference PMP242160000

Last items in stock

€832.76

VAT included 10 %

€757.05 Vat excl.

Multifunctional

The new style MultiPlus is set to replace the earlier MultiPlus Compact range. It is a powerful true sine wave inverter, a sophisticated battery charger that features adaptive charge technology and a high-speed AC transfer switch in a single compact enclosure.

Are you a dealer or installer?

For bulk purchase of Victron Energy products called the n. 0882 228247, or write to [email protected]

Inverter/Charger 1300W 24V 1600VA Victron Energy

MultiPlus 24/1600/40-16

Multifunctional

Technical Features

MultiPlus 24Volt - 24/1600/40-16

PowerControl / PowerAssist: Yes
Three Phase and parallel operation: Yes
Transfer switch: 16A

INVERTER

Input voltage range: 19 – 33V
Output Output voltage: 230VAC ± 2% Frequency: 50Hz ± 0,1%
Cont. output power at 25°C: 1600VA 1300W
Cont. output power at 40°C: 1100W
Peak power: 2800W
Maximum efficiency: 94%
Zero-load power: 9W
Zero-load power in search mode: 3W

ENCLOSURE

Material & Colour: Steel/ABS (blue RAL 5012)
Protection category: IP 21
Battery-connection: 35mm²
230V AC-connection: G-ST18i connector
Weight: 10.2 kg
Dimensions (AxLxP in mm): 470 x 265 x 120 mm

CHARGER

AC Input: Input voltage range: 187-265 VAC Input frequency: 45 – 65 Hz
Charge voltage 'absorption': 28.8V
Charge voltage 'float': 27.6V
Storage mode: 26.4V
Charge current house battery: 40A
Charge current starter battery: 1A
Battery temperature sensor: Sì

GENERAL

Programmable relay: Sì
Protection: Output short circuit; Overload; Battery voltage too high; Battery voltage too low; Temperature too high; 230VAC on inverter output; Input voltage ripple too high
VE.Bus communication port: Per funzionamento parallelo e trifase, controllo remoto e integrazione di sistema
Remote on-off: Sì
DIP switches: Sì (3)
Internal DC fuse: 125A
Operating temp. range: -40 to +65°C (fan assisted cooling)
Humidity (non-condensing): max 95%

STANDARDS

Safety: EN-IEC 60335-1, EN-IEC 60335-2-29, EN 62109-1
Emission / Immunity: EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
Road vehicles: ECE R10-5

Uninterrupted AC power (UPS function)

In the event of a grid failure, or when shore or generator power is disconnected, the inverter within the Multi is automatically activated and takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption.

Remote Monitoring and Control

Monitor and control your MultiPlus and system or systems' locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your MultiPlus to setting a Geofence for hire vehicles and more...

Description

Proven reliability
The full bridge plus toroidal transformer topology has proven its reliability over many years. The inverter is short circuit proof and protected against overheating, whether due to overload or high ambient temperature.

PowerControl - Dealing with limited generator, shore side or grid power
With the Multi Control Panel a maximum generator or shore current can be set. The MultiPlus will then take account of other AC loads and use whatever is extra for charging, thus preventing the generator or shore supply from being overloaded.

PowerAssist - Boosting the capacity of shore or generator power
Where peak power is so often required only for a limited period, the MultiPlus will make sure that insufficient shore or generator power is immediately compensated for by power from the battery. When the load reduces, the spare power is used to recharge the battery.

High start-up power
Needed to start high inrush loads such as power converters for LED lamps, halogen lamps or electric tools.

Search Mode
When Search Mode is ‘on’, the power consumption of the inverter in no-load operation is decreased by approx. 70%. In this mode the Multi, when operating in inverter mode, is switched off in case of no load or very low load, and switches on every two seconds for a short period. If the output current exceeds a set level, the inverter will continue to operate. If not, the inverter will shut down again.

Programmable relay
By default, the programmable relay is set as an alarm relay, i.e. the relay will de-energise in the event of an alarm or a pre-alarm (inverter almost too hot, ripple on the input almost too high, battery voltage almost too low).

Remote on / off / charger on
Three pole connector.
