Huawei Hybrid Inverter 3.6kW SUN2000-3.68KTL-L1 Solar Photovoltaic Accumulation Battery

SUN2000-3.68KTL-L1
Last items in stock
€1,310.66
VAT included 10 %

€1,191.51 Vat excl.

Huawei's single-phase inverters of the SUN2000 series (Smart Energy Center) are Huawei's Hybrid solution for residential connected photovoltaic systems. The particularity of these products and that are already prepared for the contextual or future insertion of lithium batteries for accumulation. All Huawei inverters comply with CEI 0-21.

100% secure payments


Hybrid Inverter Huawei 3.6kW SUN2000

Model: SUN2000-3.68KTL-L1


Huawei SUN2000 single phase

The single-phase inverter Huawei SUN2000 is a jewel of efficiency and elegance. The minimal and linear design has been awarded with the prestigious Reddot Award 2016 as the best product of the year. Its strong point is its highly reliable performance and high performance.
The Huawei inverter can reach an efficiency of 98.6%! Thanks to Huawei single-phase inverters, you are sure to make the most of your photovoltaic system production.



Strength points:

  • Character: the inverter has an attractive design and a weight of just over 10 kg;
  • Innovative:the brid inverter works in Ac and is ready for the Accumulation with Lithium Ion batteries. Management options Huawei optimizers (optional)
  • Easy to Install: It can also be installed by one person thanks to the reduced weight. It has an optimized AC connector for fast wiring and supports one-click inverter configuration
  • Safe and Reliable: integrated electronic protections Ac and Dc and IP65 protection degree with natural cooling.




Technical Specification

Input (PV)
Recommended max. PV power 5.520 Wp
Max. input voltage 600 V
MPPT operating voltage range 90 V – 560 V
Number of MPP trackers 2
Input (DC Battery)
Compatible Battery LG Chem RESU 7H_R / 10H_R
Operating voltage range 350 ~ 450 Vdc
Compatible Battery HUAWEI Smart LUNA2000 ESS Battery 5kWh – 30kWh
Operating voltage range 350 ~ 560 Vdc
Output (On Grid)
Grid connection Single phase
Rated output power 3.680 W
Max. apparent power 3.680 VA
Rated output voltage 220 Vac / 230 Vac / 240 Vac
Rated AC grid frequency 50 Hz / 60 Hz
Protection & Feature
Protection Anti-Islanding protection; DC reverse polarity protection; Insulation monitoring; DC surge protection; AC surge protection; Residual current monitoring; AC overcurrent protection; AC short-circuit protection; AC overvoltage protection; Over-heat protection; Arc fault protection; Battery reverse charging from grid.
General Data
Cooling Natural convection
Display LED indicators; integrated WLAN + FusionSolar APP
Communication RS485, WLAN via inverter built-in WLAN module Ethernet via Smart Dongle-WLAN-FE (Optional); 4G / 3G / 2G via Smart Dongle-4G (Optional)
Weight (incl. mounting bracket) 12.0 kg (26.5 lb)
Dimension (incl. mounting bracket) 365mm x 365mm x 156 mm - (14.4 x 14.4 x 6.1 inch)
Degree of protection IP65
Nighttime Power Consumption < 2.5 W
Optimizer Compatibility
DC MBUS compatible optimizer SUN2000-450W-P
Standard Compliance
Safety EN/IEC 62109-1, EN/IEC 62109-2
Grid connection standards G98, G99, EN 50549-1, CEI 0-21, VDE-AR-N-4105, AS 4777.2, C10/11,
ABNT, UTE C15-712, RD 1699, TOR D4, IEC61727, IEC62116





For more details on the product, download the Datasheet (EN) [Download]




Customer Service


0882 22 82 47

Product Code
SUN2000-3.68KTL-L1
MPPT number
2
Waveform
Pure Sine Wave
Rated Power W
3680W
Battery Voltage V
360 V
Typology
Single-phase
