2.111,06 € Vat excl.
| Input | |
| Recommended max PV power | 22,500 Wp |
| Maximum input voltage | 1,100 V |
| Max. input current for MPPT | 30 A (two strings) / 20 A (single string) |
| Max. short circuit current | 40 A |
| Starting Voltage | 200 V |
| MPPT operating voltage range | 200 V ~ 1000 V |
| Nominal input voltage | 600 V |
| Max number of inputs for MPPT | 4 |
| Number of MPPTs | 2 |
| Smart String Energy Storage System input | |
| Smart String ESS compatible | LUNA2000-5/10/15-S0 LUNA2000-7/14/21-S1 (Disponibile a partire da Q1 2024) |
| Number of battery inputs | 2 |
| Maximum charging power | 21 kW (single string) / 25 kW (two strings) |
| Maximum discharge power | 16.5 kW |
| Maximum working current | 26.25 A |
| Output | |
| Rated output power | 15,000 W |
| Max. apparent power | 16,500 VA |
| Rated output voltage | 220 Vac / 380 Vac, 230 Vac / 400 Vac, 240 Vac / 415 Vac; 3 W / N + PE |
| Nominal AC mains frequency | 50 Hz / 60 Hz |
| Maximum output current | 25.2 A / 380 Vac 23.9 A / 400 Vac 23.1 A / 415 Vac |
| Power Factor | 0.8 in anticipo ... 0.8 in ritardo |
| Features and Protections | |
| Overvoltage category | PV Ⅱ/AC Ⅲ |
| DC input switch | Yes |
| Islanding protection | Yes |
| AC overcurrent protection | Yes |
| DC reverse polarity protection | Yes |
| DC overvoltage protection | Type II |
| AC overvoltage protection | Yes, compatible with TYPE II protection class according to EN/IEC 61643-11 |
| AFCI | Integrated |
| Standard Compliance | |
| Certifications | EN/IEC62109-1, EN/IEC62109-2 |
| Network connection standards | IEC61727, IEC62116, IEC61683, EN50530, ABNT NBR 16149/16150, MEA/PEA, G99, IRR-DCC-MV/IRR-TIC, Philippine Grid Code Resolution No. 07, NRS 097-2-1, EN50549-1, VDE4105, UTE15-712-1/VFR 2019, UNE217002, NTS631, RD244(UNE217001), PPDS, ROGA, TOR Erzeuger, CEI 0-21:2020-12 V1, CEI-016, C10/C11, EN50549-2, VDE4110 |
| Compatible optimizer | |
| Compatible optimizer | SUN2000-450W-P2, SUN2000-600W-P, MERC-1100W-P, MERC-1300W-P |
| General data | |
| Display | LED indicators, integrated WLAN + FusionSolar App |
| Communication | RS485; WLAN / Ethernet via Smart Dongle-WLAN-FE (Optional) 4G / 3G / 2G via Smart Dongle-4G (Optional); EMMA (Optional; available from Q1 2024) |
| Operating temperature range | -25 °C ~ +60 °C (-13 °F ~ 140 °F) |
| Cooling down | Smart Air cooling |
| Degree of Protection | IP66 |
| Dimensions (W x H x D) | 546 x 460 x 228 mm |
| Weight | 21kg |
