100Ah 12,8V Lithium-Iron-Phosphate Batteries Smart LiFePO4 Victron Energy Solar
100Ah 12,8V Lithium-Iron-Phosphate Batteries Smart LiFePO4 Victron Energy Solar

Lithium Battery LFP 150Ah 12,8V Smart Victron Energy Photovoltaic Storage System

BAT512115610
€1,539.51
VAT included 10 %

€1,399.55 Vat excl.

Lithium-iron-phosphate (LiFePO4 or LFP) is the safest of the mainstream li-ion battery types. The nominal voltage of a LFP cell is 3,2V (lead-acid: 2V/cell).



Are you a dealer or installer?

For bulk purchase of Victron Energy products called the n. 0039 (0)882 228247 or write to [email protected]

150Ah 12,8V Lithium-Iron-Phosphate Batteries Smart

Lithium-iron-phosphate (LiFePO4 or LFP) is the safest of the mainstream li-ion battery types. The nominal voltage of a LFP cell is 3,2V (lead-acid: 2V/cell). A 12,8V LFP battery therefore consists of 4 cells connected in series; and a 25,6V battery consists of 8 cells connected in series.

Features

Rugged
A lead-acid battery will fail prematurely due to sulfation:
• If it operates in deficit mode during long periods of time (i.e. if the battery is rarely, or never at all, fully charged).
• If it is left partially charged or worse, fully discharged (yacht or mobile home during wintertime).

A LFP battery does not need to be fully charged. Service life even slightly improves in case of partial charge instead of a full charge. This is a major advantage of LFP compared to lead-acid.
Other advantages are the wide operating temperature range, excellent cycling performance, low internal resistance and high efficiency (see below).
LFP is therefore the chemistry of choice for very demanding applications.

Efficient
In several applications (especially off-grid solar and/or wind), energy efficiency can be of crucial importance.
The round trip energy efficiency (discharge from 100% to 0% and back to 100% charged) of the average leadacid battery is 80%.
The round trip energy efficiency of a LFP battery is 92%.
The charge process of lead-acid batteries becomes particularly inefficient when the 80% state of charge has been reached, resulting in efficiencies of 50% or even less in solar systems where several days of reserve energy is required (battery operating in 70% to 100% charged state).
In contrast, a LFP battery will still achieve 90% efficiency under shallow discharge conditions.

Size and weight
Saves up to 70% in space
Saves up to 70% in weight

Expensive?
LFP batteries are expensive when compared to lead-acid. But in demanding applications, the high initial cost will be more than compensated by longer service life, superior reliability and excellent efficiency.

Bluetooth
With Bluetooth cell voltages, temperature and alarm status can be monitored.
Very useful to localize a (potential) problem, such as cell imbalance.

Our LFP batteries have integrated cell balancing and cell monitoring. Up to ten batteries can be paralleled and up to four batteries can be series connected, so that a 48V battery bank of up to 3000Ah can be assembled. The cell balancing/monitoring cables can be daisychained and must be connected to a Battery Management System (BMS).

Battery Management System (BMS)
The BMS will:
1. Disconnect or shut down the load whenever the voltage of a battery cell decreases to less than 2,5V.
2. Stop the charging process whenever the voltage of a battery cell increases to more than 4,2V.
3. Shut down the system whenever the temperature of a cell exceeds 50°C.
See the BMS datasheets for more features

Technical Features

Product Code: BAT512115610

Nominal Voltage: 12.8V

Capacity: 150Ah
Dimensions(mm): 237 x 321 x 152mm

Weight: 20kg

   Downloads

  Data Sheet FR [LINK]

For all other documents to download, please visit the web site: [www.victronenergy.com]

  Customer Service

0882 22 82 47
[email protected]
Product Code
BAT512115610
Capacity (Ah)
100Ah
Typology
Lithium
Voltage (V)
12.8V
Weight
18Kg
Max. Discharge Current
300A
Recommended Maximum Charging Current
300A
Terminal
M8
Dimensions
249 x 293 x 168mm
Protections
IP22
Humidity (non - condensing)
Max 95%
Nominal capacity at 25 ° C
100Ah
Nominal capacity 0 ° C
80Ah
nominal capacity -20 ° C
50Ah
Rated power at 25 ° C
1280Wh
80% Intensity Discharge
2500 cycles
70% Intensity Discharge
3000 cycles
50% Intensity Discharge
5000 cycles
8380000036202
