Inverter 1600W 24V 2000VA Victron Energy Phoenix Compact Modello C24/2000

CIN242200000
€718.56
VAT included 10 %

€653.24 Vat excl.

Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications.
The design criteria have been to produce a true sine wave inverter with optimized efficiency but without compromise in performance. Employing hybrid HF technology, the result is a product with compact dimensions, light in weight and capable of supplying power, problem-free, to any load.



Inverter Phoenix Compact
1600W 24V 2000VA

Model: C24/2000

Developed for professional duty, the Phoenix range of inverters is suitable for the widest range of applications. The design criteria have been to produce a true sine wave inverter with optimized efficiency but without compromise in performance. Employing hybrid HF technology, the result is a top quality product with compact dimensions, light in weight and capable of supplying power, problem-free, to any load.

Technical Features

Product code: CIN242200000
Output: Uscita: 230V ± 2% / 50/60Hz ± 0,1%
Cont. output power at 25°C (VA): 2000
Cont. output power at 25°C (W): 1600
Cont. output power at 40°C (W): 1450
Cont. output power at 65°C (W): 1000
Download product Datasheet

Warranty

2 Years Guaranteed

Certifications

Features

Extra start-up power
A unique feature of the SinusMax technology is very high start-up power. Conventional high frequency technology does not offer such extreme performance. Phoenix Inverters, however, are well suited to power up difficult loads such as refrigeration compressors, electric motors and similar appliances.
Virtually unlimited power thanks to parallel and 3-phase operation capability
Up to 6 units inverters can operate in parallel to achieve higher power output. Six 24/5000 units, for example, will provide 24kW / 30kVA output power. Operation in 3-phase configuration is also possible.

To transfer the load to another AC source: the automatic transfer switch
If an automatic transfer switch is required we recommend using the MultiPlus inverter/charger instead. The switch is included in these products and the charger function of the MultiPlus can be disabled. Computers and other electronic equipment will continue to operate without disruption because the MultiPlus features a very short switchover time (less than 20 milliseconds).

Computer interface
All models have a RS-485 port. All you need to connect to your PC is our MK2 interface (see under accessories). This interface takes care of galvanic isolation between the inverter and the computer, and converts from RS-485 to RS-232. A RS-232 to USB conversion cable is also available. Together with our VEConfigure software, which can be downloaded free of charge from our website, all parameters of the inverters can be customized. This includes output voltage and frequency, over and under voltage settings and programming the relay. This relay can for example be used to signal several alarm conditions, or to start a generator. The inverters can also be connected to VENet, the new power control network of Victron Energy, or to other computerized monitoring and control systems.

New applications of high power inverters
The possibilities of paralleled high power inverters are truly amazing. For ideas, examples and battery capacity calculations please refer to our book ‘Energy Unlimited’ (available free of charge from Victron Energy and downloadable from www.victronenergy.com).

Connection Diagram




   Downloads

Datasheet EN [LINK]

For all other documents to download, please visit the web site: www.victronenergy.com

  Customer service

0039 (0)882 22 82 47
[email protected]
Product Code
CIN242200000
230 V AC-connection
Spring-clamp
Model
Phoenix Compact
Output
Output voltage: 230 VAC ±2% Frequency: 50 Hz ± 0,1%
Cont. output power at 25°C (VA) (3)
2000
Cont. output power at 25°C (W)
1600
Cont. output power at 40°C (W)
1450
Cont. output power at 65°C (W)
1000
VE.Bus communication port
For parallel and three phase operation, remote monitoring and system integration
Remote on-off
YES
Common Characteristics
Operating temperature range: -40 to +65ºC (fan assisted cooling)Humidity (non-condensing): max 95%
Common Characteristics ENCLOSURE
Material & Colour: aluminium (blue RAL 5012) Protection category: IP 21
Battery-connection
M8 bolts
Dimensions (D x W x H)
520 x 255 x 125 mm
Net Weight
12 Kg
Rated Power W
1600
Battery Voltage V
24 V
8380000002597
