The DYNESS B4850 battery module is widely used in the energy storage industry.



Dyness B4850 2.4kWh low voltage lithium battery


Main features

The DYNESS B4850 battery module is widely used in the energy storage industry. Characterized by a modular design, it can be used in residential systems. LiFEPO4 technology guarantees reliability, maximum safety and a longer life cycle.

  • Module design: expansion flexibility;
  • LFP technology for high security: cell level monitoring and balancing;
  • Different installation methods: wall, floor or stackable module installation;
  • Wide compatibility: can be combined with the main inverters.

NOTE: After completing the installation of the battery system and verifying its correct functioning, you must access the official DYNESS website to register the product and activate the warranty.
To register, go to the dyness.com website, select service -> Warranty registration and fill out the form.


For more details, download the following documents:


Technical features

A48100
Cell technology Lithium Iron Phosphate
Nominal battery energy 2.4kWh
Nominal tension 48V
Nominal capacity 50Ah
Operating voltage 42 ~ 54V
Maximum charge/discharge current Power 50A
Recommended charge/discharge current 25A
Depth of Discharge (DOD) 95%
Charging Temperature Range 0~55℃
Discharge Temperature Range -20~55℃
Life cycle ≥6000 cycles
Communication CAN/RS485
Dimensions 480 x 405 x 90 mm
Weight 22 kg
Advantages Can be used in both off-grid and hybrid configurations, compact design
Compatible inverters SMA/Victron/Ingeteam/Delios/Goodwe/Solis/Deje/SAJ/Voltronic/Sungrow etc.
Certification and safety standards UN38.3/CE-EMC/IEC62619/IEC62040/CEC accreditato/CEI-021/UL1973/REACH/ROHS/UKCA/GOST-R


Customer service


0882 22 82 47

Typology
Lithium
Voltage (V)
48V
Accumulation capacity
2.4kW
