Smartsolar MPPT Charge Controller 150/70-TR VE.Direct 150Voc 70A Victron Energy
Smartsolar MPPT Charge Controller 150/70-TR VE.Direct 150Voc 70A Victron Energy
Smartsolar MPPT Charge Controller 150/70-TR VE.Direct 150Voc 70A Victron Energy
Smartsolar MPPT Charge Controller 150/70-TR VE.Direct 150Voc 70A Victron Energy

Charge Controller MPPT Smartsolar 150/70-TR VE.CAN 150Voc 70A Victron Energy

SCC115070411
Delivery: 7 days
€447.72
VAT included 10 %

€407.02 Vat excl.

A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.



Solar Charge Controller MPPT SmartSolar

150/70-Tr VE.Direct 150Voc 70A

Solar charge controller

A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life.

MPPT: Ultra Fast Maximum Power Point Tracking



By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology ensures that every drop of available power is rinsed out of your panels, and harvested for storage.

The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing.

Remote Monitoring and Control



Remotely control and monitor the extensive features of your SmartSolar MPPT charger with built-in bluetooth by pairing it with your smartphone or other device via VictronConnect. If your installation is connected to the internet Victron Remote Management Portal (VRM) provides access to the full power of your MPPT, anytime, anywhere; both services are free to use. For remote installations - even when there is no internet connection or phone signal nearby - you may be able to monitor your MPPT by bluetooth-pairing with a LoRaWAN (long-range wide area network) device, available optionally.

Optional SmartSolar Control Display



By adding the SmartSolar Control Display you will be able to check the status of your Charger and battery-storage at a glance.

Simply plug it into the face of your MPPT charger to provide you with real-time monitoring and set-up capabilities.

Features

Ultra-fast Maximum Power Point Tracking (MPPT)
Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.

Advanced Maximum Power Point Detection in case of partial shading conditions
If partial shading occurs, two or more maximum power points may be present on the powervoltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative SmartSolar algorithm will always maximize energy harvest by locking to the optimum MPP.

Outstanding conversion efficiency
No cooling fan. Maximum efficiency exceeds 98%.

Flexible charge algorithm
Fully programmable charge algorithm, and eight preprogrammed algorithms, selectable with a rotary switch (see manual for details).

Extensive electronic protection
Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection.

Internal temperature sensor
Compensates absorption and float charge voltage for temperature.

Bluetooth Smart built-in: dongle not needed
The wireless solution to set-up, monitor and update the controller using Apple and Android smartphones, tablets or other devices.

VE.Direct
For a wired data connection to a Color Control GX, other GX products, PC or other devices

Remote on-off
To connect for example to a VE.BUS BMS.

Programmable relay
Can be programmed (a.o. with a smartphone) to trip on an alarm, or other events.

Optional: pluggable LCD display
Simply remove the rubber seal that protects the plug on the front of the controller, and plug-in the display.

Technical Features

  • Model: SCC115070410

CHARGE CONTROLLER

  • Battery voltage: 12 / 24 / 48V Auto Select (software tool needed to select 36V)
  • Rated charge current: 70A
  • Nominal PV power: 12V 1000W; 24V 2000W; 36V 3000W; 48V 4000W
  • Max. PV short circuit current: 50A
  • Maximum PV open circuit voltage: 150V absolute maximum coldest conditions 145V start-up and operating maximum
  • Maximum efficiency: 98%
  • Self-consumption: Less than 35mA @ 12V / 20mA @ 48V
  • Charge voltage 'absorption': Default setting: 14,4 / 28,8 / 43,2 / 57,6V (adjustable with: rotary switch, display, VE.Direct or Bluetooth)
  • Charge voltage 'float': Default setting: 13,8 / 27,6 / 41,4 / 55,2V (adjustable: rotary switch, display, VE.Direct or Bluetooth)
  • Charge voltage 'equalization': Default setting: 16,2V / 32,4V / 48,6V / 64,8V (adjustable)
  • Charge algorithm: multi-stage adaptive (eight preprogrammed algorithms) or user defined algorithm
  • Temperature compensation: -16 mV / -32 mV / -64 mV / ° C
  • Protection: Battery reverse polarity (fuse, not user accessible) PV reverse polarity / Output short circuit / Over temperature
  • Operating temperature: -30 to +60°C (full rated output up to 40°C)
  • Humidity: 95%, non-condensing
  • Maximum altitude: 5000m (full rated output up to 2000m)
  • Environmental condition: Indoor, unconditioned
  • Pollution degree: PD3
  • Data communication port: VE.Direct or Bluetooth
  • Remote on/off: Yes (2 pole connector)
  • Programmable relay: DPST AC rating: 240VAC / 4A DC rating: 4A up to 35VDC, 1A up to 60VDC
  • Parallel operation: Yes (notsynchronized)

ENCLOSURE

  • Colour: Blu (RAL 5012)
  • PV terminals: 35 mm² / AWG2
  • Battery terminals: 35mm² / AWG2
  • Protection category: IP43 (electronic components), IP22 (connection area)
  • Weight: 3Kg
  • Dimensions (h x l x p): 185 x 250 x 95 mm

STANDARDS

  • Safety: EN / IEC 62109-1, UL 1741, CSA C22.2

   Downloads

Datasheet EN [LINK]
User Manual EN [LINK]

  Customer Service

0882 22 82 47
[email protected]
Product Code
SCC115070411
Technology (MPPT - PWM)
MPPT
Nominal system voltage (VDC)
12 / 24 / 36 / 48 VDC Auto work
Rated Battery Current
85A
Max. PV input power
12V (1000W)24V (2000W)36v (3000W)48V (4000W)
Self-consumption
12V (35 mA)48V (20 mA)
Terminal
35 mm²
Working temperature
-30°C - +60°C
Overall dimension
185 x 250 x 95 mm
Net weight
3kg
8719076050322
