1.473,22 € Vat excl.
Panel solar fotovoltaico de doble cara N-type TOPCon Doble Vidrio 620W con celula en silicio monocristalino, ideal para la construcción de sistemas fotovoltaicos se conecta con las redes (sistemas fotovoltaicos conectados a la red) y dos fotovoltaica autónoma (PV instalaciones fuera de la red).
| ELECTRICAL CHARACTERISTICS | |
| MODEL | HSM-ND66-GR620 |
| Peak Power (Pmax) | 620W |
| Voltage at Pmax (Vmp) | 40.98V |
| Current at Pmax (Imp) | 15.13A |
| Open Circuit Voltage (Voc) | 48.94V |
| Short Circuit Current (Isc) | 16.05A |
| Maximum System Voltage | 1500V DC (IEC) |
| Maximum Series Fuse Rating | 30A |
| Module Efficiency | 23.0% |
| MECHANICAL CHARACTERISTICS | |
| Number of Cells | 132 |
| Solar Cells | N-type TOPCon module |
| Frame | anodized aluminum alloy |
| Junction Box | IP68, 3 diodes |
| Connectors | Stäubli MC4-EVO2 |
| Dimensions | 2382 × 1134 × 30 mm |
| Weight | 32.6 kg |
| Packaging | 36 pieces per pallet |
| Certifications | Standard IEC 61215, IEC 61730 Fire rating class A (IEC 61730-2 / UL 790) Protection class II (IEC 61140) |
